SS304/SS316L Stainless Steel Basket Strainers for Manufacturing Plant

Stainless Steel basket strainer basket type filter specification:

Standard:ASME Code

Vessel Material: Carbon Steel, Stainless Steel

Filter Element Material: S S square mesh screen, spiral wound pipe, perforated plate, etc.

Element Strength:> 1Mpa

Vessel Diameter: <1200mm

Filter Precision: 50~2000microns

Basket type filter a small equipment which is used to remove small amount of solid particles in water,which consists of connecting pipe,main pipe,filtration basket,flange,blind flange and fastener,etc.When the liquid flows into the filtration basket through main pipe.solid impurity particles are blocked in the filtration basket,but the clean liquid will flow through the basket and be discharged through sewage outfall.when it needs to be cleaned,unscrew the bottom plug of main pipe,discharge the liquid and disassemble the blind flange,and assembly it again after cleaning.so it is easy to operate and maintain.

Stainless Steel basket strainer basket type filter advantages:

1. high efficient
2. power-effective

It is used filter impurities. According to your requirement, we can supply you the exact products.

It is a nonstandard article. Hence, further understanding will lead further cooperation.

If you have further interest, please let us know.

Stainless Steel basket strainer basket type filter Features:

• Divided into two types, i.e., with jacket or without jacket.
• The materials of filter can be designed according to the needs of customers.
• Its outer surface is treatment by shot blastign or polishing, beautiful & elegant, while its welding seam is treated of acid cleaning and passivation, so as to increase its anti-corrosion capacity.
• The relative position of inlet/outlet and installation height can be customized to suit the specific requirements of applications.

Main Technological Parameters:
